Fractal Design Tesla R2 650W Power Supply Review

We are going to look at a 80 plus Gold rated power supply for mid level and budget PCs, the Fractal Design Tesla R2 650W PSU. The Tesla R2 series of PSU’s were designed and created by Fractal to ” provide clean power efficiently and quietly” according to the Telsa R2 650W PSU webpage. They appearance of the Tesla R2 line was built for “providing innovative computer components infused with stylish, elegant, contemporary Scandinavian design”. The whole Tesla R2 line consist also of a 500W, 800W, 1000W PSU in addition to the 650W.

Fractal Design Tesla R2 650W PSU

Fractal Design Tesla R2 650W PSU

Fractal Design Tesla R2 650W PSU

Fractal Design Tesla R2 650W PSU

Fractal Design Tesla R2 650W PSU Features and Specifications

General Specifications

Wattage Range 650W
80PLUS Certification Gold
Modular Cables No
Fan Type 135 mm ball bearing
Maximum Operating Temperature at full load 40 C
Semi-passive Operation No
Capacitors Taiwanese
Colors Avaliable Black and White
Mean Time Between Failures (MTBF) 100,000 hours at full load
PSU Specification Compliance ATX 2.31
PSU Case Dimensions 150 mm W x 86 mm H x 165 mm D
Warranty 3 Years
Fractal Design Tesla R2 650W PSU

Fractal Design Tesla R2 650W PSU
